8000cph 60 Feeders SMT Mounter Machine PCB Assembly Machine With Embedded Linux System
CHM-T560P4 Introduction
CHM-T560P4 has 4 heads, mounting speed is faster. For small SMT production, it is your good helper!
The operation system is embedded Linux system, the main board of machine was researched by ourselves, which is more reliable than windows system, and life time is much longer. it use 502---507 different kinds of Juki nozzles, suitable for 0402,0603,0805-5050, SOP, QFN, LQFP, Diode, Transistor, BGA...etc, which can meet more customers' demand.
Specifications
| CHM-T560P4 Specifications |
| Dimensions | 1180mm(L)×870mm(W)×640mm(H) |
| Weight | 140kg |
| Power Supply | AC220V (50Hz, single phase) /AC110V (60Hz, single phase); 400W |
| Air Supply | 0.5MPa ~0.7MPa |
| Vacuum Generation | Built-in vacuum pump |
| Mounting Head Quantity | 4 |
| Mounting Speed | 8000cph(optimal without vision detection); 5500cph (optimal with vision detection) |
| Control Accuracy | 0.015mm |
| Component Type | 0402/0603～5050/SOT/SOP/QFP/QFN/BGA, etc. (resistor/capacitor/diode/triode/LED/IC, etc.) |
| PCB Thickness | 0.6mm~3.5mm |
| PCB Size | 10mm(L)×10mm(W)～400mm(L)×290mm(W) |
| PCB Conveying | Manual operation |
| Nozzle Change | Manual operation |
| Control System | Built-in computer (embedded Linux operating system), 7-inch touch screen |
| Drive System | X&Y-axis driven by stepping motors in the way of closed-loop control; Z-axis capable of reset detection;all motors adopting flexible S-curve acceleration and deceleration |
| Transmission System | Synchronous belt + linear guide |
| Feeding System | 60 Yamaha 8mm standard pneumatic feeder stacks (also suitable for Yamaha electric feeder, IC tray, and stick feeder), 11 preset general IC stacks, worksurface custom IC trays supported |
| Vision System | Up-looking camara for component automatic calibration (component size applicable: 22mm×22mm); down-looking camera for PCB calibration via Mark Point and component positioning |
Industry mainstream SMT machine:widely used in various industries,for example:school teaching,lab proofing,start a business,processing...etc.
Four Heads Mount
4 heads work at the same time ,and the stability is better. It can be rotated at any time by 360 degrees. The angle rotation is linked without affecting the placement efficiency. The Z-axis detection can self-check the height and angle of 4 heads ,compatible with JUKI high-precision nozzles,up to 9 models ,suitable for all packaged ship devices easy and fast to replace the heads by hand
Our Service
This SMT machine will be tested well before ship out.
Tools and manuals are complete included in the package.
We provide online Q/A and troubleshooting support and technical advice service.
Provide one to one after-sale service.
