Fully automatic 4-head small-sized vision pick and place machine

60 feeder base/4 heads mounting/

Mounting speed  up to 8000CPH without vision detection

Built-in computer, embedded Linux operating system

7-inch touch screen

Operating system self developed and researched

simple and easy to learn

Software enjoys long life service.

Real mounting speed can up to 5500CPH

Improve efficiency& work more easily

Operating system self developed and researched

simple and easy to learn

Software enjoys long life service.

Real mounting speed can up to 5500CPH

Improve efficiency& work more easily

Step-servo motor with Closed-loop control positioning is more stable,low noise .smooth and accuracy high-speed response

Linear guides, high precision,low noise,long life span , high resistance for bending deformation UM level positioning accuracy can be reached.

Importing synchronous belt. High resistance of abrasion ,aging and deformation suitable for high torque transmission

Support MAX size 400*290mm,applicable for different kinds technology of PCB mounting (600*300mm can be customized)

Double vision Calibration

1,Automatically adjust to ensure the mounting accuracy

2.Double calibration can accurately mount IC devices.

3.Automatically correct feeding error.

4.Using industrial high precision CCD to collect IC pins,more accurate calculation.

UP-looking camera. Picking error can be adjusted automatically, accurately identify the smallest 0402 and the 0.5mm pin gap

Down-looking camera. Identify mark point position&pick location automatically. calibrate PCB abnormal, set up identifying of PCB one by one.

Heads mounting : 2 heads picking at the same time

4 independant rotary motors can mount at any angle.Z axis route length 15MM, applicable for special height of component's mounting

Built-in industrial computer,embedded linux operating system.

Touch screen operation with the mouse, more compatible more simply
